Exceeding Expectations

Our DR system is equipped with uVision remote technology, which integrates the virtual detector profile, remote collimation and stitching range adjustment functionalities. United Imaging is leading X-ray imaging into a new era by enabling cross-room control, real-time patient video monitoring, and an accelerated exam workflow in an ever-changing clinical environment.

High scanning performance

uVision

Efficient inspection

Automatic Tube-detector Tracking System

Convenient operation

Automatic Stitching Technology

DR system is equipped with uVision remote technology

Innovative All-In Configuration

Large Coverage Wireless HD Flat Panel Detector

Large Coverage Wireless HD Flat Panel Detector

The 17"x17" large HD Flat Panel Detector is flexible to accommodate a wide range of imaging and positioning requirements.

Built-in Detector Charging

Built-in Detector Charging

Easy access to charging provides long lasting detector performance.

One-key APR Positioning

One-key APR Positioning

Single-click positioning offers a seamless clinical workflow for all patient positioning needs to significantly boost exam efficiency.

Easy-to-use Auto or Manual

Easy-to-use Auto or Manual

The advanced electro-mechanical motor-driven system enables both automatic and manual operation. Built-in movement assistance and safeguard functionalities ensure operator efficiency and patient safety.

Comprehensive Clinical Applications

imaging with Automatic Stitching Technology

Automatic Stitching Technology

Automatic Smart Stitching Technology offers high quality panoramic imaging for erect and supine positions, it is ideal for streamlined orthopedic imaging workflow and increased diagnostic confidence.

imaging with Measurement Technology*

Measurement Technology*

Integrated vertebral Cobb angle and femoral collo-diaphyseal angle measurement functions provide precise guidance to preoperative and postoperative evaluation.

Clinical Application

Foot AP & Oblique
Foot AP & Oblique
Chest PA
Chest PA
Chest LAT
Chest LAT
Whole Spine AP & LAT
Whole Spine AP & LAT
Cervical Vertebrae AP & LAT
Cervical Vertebrae AP & LAT
Lumber Vertebrae AP & LAT
Lumbar Vertebrae AP & LAT
Technical Details
  • Detector
  • X-ray Tube
  • HV Generator

Detector



Detector type

Wireless Flat Panel Detector

Scintillator

Cesium Iodide (CSI)

Pixel Size

139μm

Pixel Matrix

3072 x 3072

X-ray Tube



Tube type

Rotating Anode X-ray Tube

Anode target material

Rhenium-Tungsten faced Molybdenum

Focal spot size

0.6mm / 1.2mm

Anode target angle

12°

HV Generator



Max. Output Power

65kW / 80kW

Range of kV

40kV-150kV

Range of mA

10mA~800mA (65kW)
10mA~1000mA (80kW)

Disclaimer:

The product may not be commercially available in all countries. Please check with your local United Imaging Healthcare representative for availability.

This product is intended for use by trained medical professionals only. Patients should follow the guidance and instructions provided by healthcare practitioners during operation.

Please contact your local United Imaging Healthcare organization for further details.
